KBA Series lighting busway can provide independent or combined use of lighting and power.
Features:
-Quick & easy to install.
-Three-phase design.
-All parts are non-halogen,it will not release toxic gases in the fire case.
- Aluminum-magnesium alloy housing, with excellent load-bearing capacity.
-Water and dust protection is IP55.
Specification:
-Current: 25A~ 40A
-Voltage: 220~400V
-Conductor material: Tin copper
-Conductor quantity: 2~8
-Standard length: 2m, 3m
-Protection level: IP55
Technical parameters:
Single circuit busbway
Our lighting busway can applied to the following areas:
-Electronic manufacturing lines
-Sewing machines lines
-Automobile assembly lines
-Machine manufacturing line
-Commercial production & assembly lines
-Machine shop and factories machine power supply
-Clean room power supply
-Work stations power supply
-Factories, warehouse, parking area lighting
-School, R&D Lab. power supply
-Shopping mall, Shop, Commercial/retail lighting
-Commication &computer center power supply
-Office power supply & lighting
-Museum, Art museum & exhibition center lighting
KB series lighting busway main components as below:
-Straight element
1. Rated current: 25A, 40A
2. Conductor qty: 2 or 4
3. Standard length: 2m, 3m
-Feeder units and end cap
Feeder units are used to connect cable and straight elements. End caps are used to seal busbar terminal.
-Fixing brackets
Fixing brackets can fix luminaires and busbar.
-Tap-off units
-Flexible joint
It can change direction and bypass the obstacles, and the installation method is same as straight element.
